Label Flex-ST

LABEL FLEX ST is used to print on label tags material and give output on A4 sheet size. A4 LABEL SHEET CUTTING & PRINTING MACHINE is known for high-speed printing with the best accuracy. It’sa modular design and precise rigid construction provide the versatility and reliability necessary for the most difficult jobs. The label flex stationery press can be assembled to your specifications in various widths.

It has full dual side frames to create a solid and rigidstructure. Consistent repeatable quality printing is facilitated by the ease of operating the label flex. Precise print adjustments are made quickly, even when changing material. Doctor blades, plate cylinders, and anilox rolls can be changed quickly even after the job is set up, and the close-loop tension system provides exact and repeatable control at the operator-selected tension level.

Technical Specification

Printing Width 350mm
Machine Type Mechanical, Infeed/Outfeed Servo, Full Servo
Printing/Die cutting Repeat A4
Max Parent Reel Dia 1000 mm
No. of Colors Upto 2 Color
Output Reel, Sheet
Rewind Dia. 600mm
Speed 120-150m/min (Depend on Substrate)
Wastage Rewind Dia 508mm


  • Roll To Roll Printing
  • Roll-To-Sheet Printing
  • UV Dryer/Hot Air Dryer
  • High Speed
  • 360° Registration Gear Box
  • Turn Bar
  • Web Video Inspection
  • Cold Foil Stamping
  • Sheeter/Stacker Conveyor
  • Digital Printing
  • Inkjet Solution
